class: center, middle, inverse, title-slide # Intro to <code>tidymodels</code> with <code>nflscrapR</code> play-by-play ### Thomas Mock: <code>@thomas_mock</code> ### 2020-05-21 --- ## Before we get started, thank you to: .pull-left[ ### The `nflscrapR` team: (data from 2009-current) * Maksim Horowitz * Ron Yurko * Sam Ventura * Rishav Dutta ### The `nflfastR` team: (data from 2000-current) * Ben Baldwin * Sebastian Carl ] .pull-right[ <img src="https://pbs.twimg.com/profile_images/1076883081192263680/hj53KzOl_400x400.jpg" width="50%" /> <br> <img src="https://raw.githubusercontent.com/mrcaseb/nflfastR/master/man/figures/logo.png" width="50%" /> ] These datasets set the bar for publicly-available NFL data! --- ### Twitter-driven Development .pull-left[ <blockquote class="twitter-tweet"><p lang="en" dir="ltr">Super excited to be joining in on the next <a href="https://twitter.com/hashtag/HANIC?src=hash&amp;ref_src=twsrc%5Etfw">#HANIC</a> chat on May 21st - NFL crossover edition!<br><br>Got invited to give a 10 min talk - potential talks below that I&#39;d like to hear your potential interest in (all would be built around NFL data)<a href="https://twitter.com/hashtag/nflscrapR?src=hash&amp;ref_src=twsrc%5Etfw">#nflscrapR</a> <a href="https://twitter.com/hashtag/rstats?src=hash&amp;ref_src=twsrc%5Etfw">#rstats</a></p>&mdash; Tom Mock (@thomas_mock) <a href="https://twitter.com/thomas_mock/status/1260273131991810049?ref_src=twsrc%5Etfw">May 12, 2020</a></blockquote> <script async src="https://platform.twitter.com/widgets.js" charset="utf-8"></script> ] .pull-right[ Of course the highest voted submission was for a resource I had yet to write! 🤦 🤦 🤦 Other long-form writeups I have completed for y'all * [`nflscrapR` dataviz w/ `ggplot2`](https://jthomasmock.github.io/nfl_plotting_cookbook/#how_to_improve_your_nflscrapr_graphics) * [Using R w/ SQL through `dbplyr` for `nflfastR`](https://themockup.blog/posts/2019-04-28-nflfastr-dbplyr-rsqlite/) * [Multiple tidy `nflscrapR` models at once w/ `broom` + `dplyr`](https://themockup.blog/posts/2020-05-01-tidy-long-models/) ] --- ### Personas * You've done some modeling in R 💻 + 📈 -- * You're interested in fitting models in R with sports data 💻 + 📈 + 🏈 -- * You're new to `tidymodels` AND you want to fit models to sports data 💡 + 💻 + 📈 + 🏈 -- * You're awesome because you came to HANIC! 🙌 🏒 -- #### Slide Link: [`jthomasmock.github.io/nfl_hanic/`](https://jthomasmock.github.io/nfl_hanic/) #### Repo w/ Code: [`github.com/jthomasmock/nfl_hanic`](https://github.com/jthomasmock/nfl_hanic) --- # `tidymodels` The `tidymodels` framework is a collection of packages for modeling and machine learning using `tidyverse` principles. ## Packages * `rsample`: efficient data splitting and resampling * `parsnip`: tidy, unified interface to models * `recipes`: tidy interface to data pre-processing tools for feature engineering * `workflows`: bundles your pre-processing, modeling, and post-processing * `tune`: helps optimize the hyperparameters and pre-processing steps * `yardstick`: measures the performance metrics * `broom`: converts common R statistical objects into predictable formats * `dials`: creates and manages tuning parameters/grids --- ### The Dataset Filtered down from the `nflscrapR` and `nflfastR` datasets (~2.25 GB) to only non-penalty run and pass plays from 2000 and 2019. This is about 17 million data points across ~630 thousand plays. #### The goal: Predict if an upcoming play will be a `run` or a `pass` .tiny[ ```r Rows: `628,602` Columns: `28` $ game_id <dbl> 2000090300, 2000090300, 2000090300, 2000090300, 2000090… $ game_date <dbl> 11203, 11203, 11203, 11203, 11203, 11203, 11203, 11203,… $ game_seconds_remaining <dbl> 3600, 3544, 3537, 3520, 3520, 3520, 3520, 3520, 3359, 3… $ week <dbl> 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1… $ season <fct> 2000, 2000, 2000, 2000, 2000, 2000, 2000, 2000, 2000, 2… $ play_type <fct> run, pass, pass, run, run, run, pass, pass, pass, run, … $ yards_gained <dbl> 2, 0, 0, 8, 3, -1, 15, 11, 0, 3, 0, -1, 5, 7, 0, -1, 13… $ ydstogo <dbl> 10, 8, 8, 10, 2, 10, 11, 10, 10, 10, 7, 10, 11, 6, 10, … $ down <fct> 1, 2, 3, 1, 2, 1, 2, 1, 1, 2, 3, 1, 2, 3, 1, 2, 3, 1, 2… $ yardline_100 <dbl> 65, 63, 63, 78, 70, 67, 68, 53, 42, 42, 39, 94, 95, 90,… $ qtr <fct> 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1… $ posteam <fct> ARI, ARI, ARI, NYG, NYG, NYG, NYG, NYG, NYG, NYG, NYG, … $ posteam_score <dbl> 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0… $ defteam <fct> NYG, NYG, NYG, ARI, ARI, ARI, ARI, ARI, ARI, ARI, ARI, … $ defteam_score <dbl> 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0… $ score_differential <dbl> 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0… $ shotgun <fct> 0, 0, 1, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 1, 0, 0, 1, 0, 0… $ no_huddle <fct> 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0… $ posteam_timeouts_remaining <fct> 3, 3, 3, 3, 3, 3, 3, 3, 3, 3, 3, 3, 3, 3, 3, 3, 3, 3, 3… $ defteam_timeouts_remaining <fct> 3, 3, 3, 3, 3, 3, 3, 3, 3, 3, 3, 3, 3, 3, 3, 3, 3, 3, 3… $ wp <dbl> 0.5277650, 0.5188163, 0.4902653, 0.4967958, 0.5223148, … $ goal_to_go <fct> 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0… $ in_red_zone <fct> 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0… $ in_fg_range <fct> 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0… $ two_min_drill <fct> 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0… $ total_runs <dbl> 0, 1, 1, 0, 1, 2, 3, 3, 3, 3, 4, 1, 2, 2, 3, 3, 4, 4, 5… $ total_pass <dbl> 0, 0, 1, 0, 0, 0, 0, 1, 2, 3, 3, 2, 2, 3, 3, 4, 4, 5, 5… $ previous_play <fct> First play of Drive, run, pass, First play of Drive, ru… ``` ] --- ### Data Prep I don't want to get lost in the weeds on data prep or feature engineering, but for future reference here are the `filter` and `mutate` steps I applied. I also use `dbplyr` to pull the data in so that I could work with the 2.2 GB of data on disk and only pull into memory the specific rows/columns I wanted to work with. Full details about `dbplyr` + `nflfastR` data on my [blog](https://themockup.blog/posts/2019-04-28-nflfastr-dbplyr-rsqlite/). .small[ ```r pbp_db <- tbl(DBI::dbConnect(RSQLite::SQLite(), "data/pbp_db.sqlite"), "pbp_clean_2000-2019") raw_plays <- pbp_db %>% select( game_id, game_date, game_seconds_remaining, season_type, week, season, play_type, yards_gained, ydstogo, down, yardline_100, qtr, posteam, posteam_score, defteam, defteam_score, score_differential, shotgun, no_huddle, posteam_timeouts_remaining, defteam_timeouts_remaining, penalty, wp, goal_to_go, half_seconds_remaining ) %>% filter( play_type %in% c("run", "pass"), penalty == 0, season_type == "REG", !is.na(down), !is.na(yardline_100) ) %>% mutate( in_red_zone = if_else(yardline_100 <= 20, 1, 0), in_fg_range = if_else(yardline_100 <= 35, 1, 0), two_min_drill = if_else(half_seconds_remaining <= 120, 1, 0) ) %>% select(-penalty, -season_type, -half_seconds_remaining) %>% collect() ``` ] --- ### Feature Engineering I added a few features, namely a running total of number of runs/passes pre-snap and what the previous play was. .small[ ```r all_plays <- raw_plays %>% group_by(game_id, posteam) %>% mutate( run = if_else(play_type == "run", 1, 0), pass = if_else(play_type == "pass", 1, 0), total_runs = if_else(play_type == "run", cumsum(run) - 1, cumsum(run)), total_pass = if_else(play_type == "pass", cumsum(pass) - 1, cumsum(pass)), previous_play = if_else(posteam == lag(posteam), lag(play_type), "First play of Drive" ), previous_play = if_else(is.na(previous_play), replace_na("First play of Drive"), previous_play ) ) %>% ungroup() %>% mutate_at(vars( play_type, season, posteam, defteam, shotgun, down, qtr, no_huddle, posteam_timeouts_remaining, defteam_timeouts_remaining, in_red_zone, in_fg_range, previous_play, goal_to_go, two_min_drill ), as.factor) %>% select(-run, -pass) ``` ] --- ## Data Splitting w/ `rsample` Now that I've created the dataset to use, I'll start with `tidymodels` proper. Do the initial split and stratify by play type (make sure there are equal ratios of run vs pass in `test` and `train`) ```r split_pbp <- initial_split(all_plays, 0.75, strata = play_type) split_pbp # separate the training data train_data <- `training(split_pbp)` # separate the testing data test_data <- `testing(split_pbp)` ``` --- ### Test vs Train Split into `training` and `testing` and then confirm the ratios. .medium[ ```r train_data %>% count(play_type) %>% mutate(ratio = n/sum(n)) ``` ```r # A tibble: 2 x 3 # play_type n ratio # <fct> <int> <dbl> # 1 `pass 270979 0.575` # 2 run 200473 0.425 ``` ```r test_data %>% count(play_type) %>% mutate(ratio = n/sum(n)) ``` ```r # A tibble: 2 x 3 # play_type n ratio # <fct> <int> <dbl> # 1 `pass 90326 0.575` # 2 run 66824 0.425 ``` ] --- ## Add recipe steps with `recipes` `recipe` steps are changes we make to the dataset, including things like centering, dummy encoding, update columns as ID only, or even custom feature engineering. ```r pbp_rec <- recipe(play_type ~ ., data = train_data) %>% # ignore these vars for train/test, but include in data as ID update_role(game_id, game_date, yards_gained, new_role = "ID") %>% # removes vars that have large absolute correlations w/ other vars step_corr(all_numeric(), threshold = 0.7) %>% step_center(all_numeric()) %>% # substract mean from numeric step_zv(all_predictors()) # remove zero-variance predictors ``` --- ## Choose a model and start your engines! `parsnip` supplies a general modeling interface to the wide world of R models! ```r # Note that mode = "classification" is the default here anyway! lr_mod <- logistic_reg(mode = "classification") %>% set_engine("glm") ``` --- ## Combine into a `workflow` We can now combine the model and recipe into a `workflow` - this allows us to define exactly what model and data are going into our `fit`/train call. ```r lr_wflow <- workflow() %>% add_model(lr_mod) %>% # parsnip model add_recipe(pbp_rec) # recipe from recipes ``` ### What is a `workflow`? A workflow is an object that can bundle together your pre-processing, modeling, and post-processing requests. For example, if you have a `recipe` and `parsnip` model, these can be combined into a workflow. The advantages are: * You don’t have to keep track of separate objects in your workspace. * The recipe prepping and model fitting can be executed using a single call to `fit()`. * If you have custom tuning parameter settings, these can be defined using a simpler interface when combined with `tune`. --- ## Fit/train the model with `parsnip` Now we can move forward with fitting/training the model - this is really a one-liner. ```r pbp_fit_lr <- lr_wflow %>% fit(data = train_data) # fit the model against the training data ``` --- ## Predict outcomes with `parsnip` After the model has been trained we can compare the training data against the holdout testing data. ```r pbp_pred_lr <- predict(pbp_fit_lr, test_data) %>% # Get probabilities for the class for each observation bind_cols(predict(pbp_fit_lr, test_data, type = "prob")) %>% # Add back a "truth" column for what the actual play_type was bind_cols(test_data %>% select(play_type)) ``` --- ### Check outcomes with `yardstick` For confirming how well the model predicts, we can use `yardstick` to plot ROC curves, get AUC and collect general metrics. .pull-left[ .small[ ```r pbp_pred_lr %>% # get Area under Curve roc_auc(truth = play_type, .pred_pass) pbp_pred_lr %>% # collect and report metrics metrics(truth = play_type, .pred_class) ``` ```r # A tibble: 1 x 3 # .metric .estimator .estimate # <chr> <chr> <dbl> # 1 `roc_auc binary 0.761` # A tibble: 2 x 3 # .metric .estimator .estimate # <chr> <chr> <dbl> # 1 `accuracy binary 0.701` # 2 kap binary 0.384 ``` ] ] .pull-right[ .small[ ```r pbp_pred_lr %>% # calculate ROC curve roc_curve(truth = play_type, .pred_pass) %>% # ggplot2 autoplot for AB line # and the path of ROC curve autoplot() ``` ]  ] --- **Split** .small[ ```r # Split split_pbp <- initial_split(all_plays, 0.75, strata = play_type) # Split into test/train train_data <- training(split_pbp) test_data <- testing(split_pbp) ``` **Pre-Process & Choose a model** ```r # Create a pre-processing recipe pbp_rec <- recipe(play_type ~ ., data = train_data) %>% update_role(game_id, game_date, yards_gained, new_role = "ID") %>% step_corr(all_numeric(), threshold = 0.7) %>% step_center(all_numeric()) %>% step_zv(all_predictors()) # Choose a model and an engine lr_mod <- logistic_reg(mode = "classification") %>% set_engine("glm") ``` **Combine into a workflow** ```r # Combine the model and recipe to the workflow lr_wflow <- workflow() %>% add_model(lr_mod) %>% add_recipe(pbp_rec) # Fit/train the model pbp_fit_lr <- lr_wflow %>% fit(data = train_data) ``` **Predict and get metrics** ```r # Get predictions pbp_pred_lr <- predict(pbp_fit_lr, test_data) %>% bind_cols(predict(pbp_fit_lr, test_data, type = "prob")) %>% bind_cols(test_data %>% select(play_type)) # Check metrics pbp_pred_lr %>% metrics(truth = play_type, .pred_class) ``` ] --- ## Change the model How about a Random Forest model? Just change the model and re-run! ```r rf_mod <- rand_forest(trees = 1000) %>% set_engine("ranger", importance = "impurity", # variable importance num.threads = 4) %>% # Parallelize set_mode("classification") rf_wflow <- workflow() %>% `add_model(rf_mod)` %>% # New model add_recipe(pbp_rec) # Same recipe pbp_fit_rf <- rf_wflow %>% # New workflow fit(data = train_data) # Fit the Random Forest # Get predictions and check metrics pbp_pred_rf <- `predict(pbp_fit_rf, test_data)` %>% bind_cols(test_data %>% select(play_type)) %>% bind_cols(predict(pbp_fit_rf, test_data, type = "prob")) ``` --- ### Quick comparison The random forest model slightly outperforms the logistic regression, although both are not great ```r `pbp_pred_rf` %>% # Random Forest predictions metrics(truth = play_type, .pred_class) `pbp_pred_lr` %>% # Logistic Regression predictions metrics(truth = play_type, .pred_class) ``` ```r # A tibble: 2 x 3 # .metric .estimator .estimate # <chr> <chr> <dbl> # 1 accuracy binary `0.722` # 2 kap binary 0.433 # # A tibble: 2 x 3 # .metric .estimator .estimate # <chr> <chr> <dbl> # 1 accuracy binary `0.701` # 2 kap binary 0.384 ``` --- ### Feature Importance .small[ ```r pbp_fit_rf %>% pull_workflow_fit() %>% vip(num_features = 20) ``` ]  --- ### Comparing Models Together .small[ .pull-left[ ```r roc_rf <- pbp_pred_rf %>% `roc_curve(truth = play_type, .pred_pass)` %>% mutate(model = "Random Forest") roc_lr <- pbp_pred_lr %>% `roc_curve(truth = play_type, .pred_pass)` %>% mutate(model = "Logistic Regression") full_plot <- bind_rows(roc_rf, roc_lr) %>% # Note that autoplot() would also work here! ggplot(aes(x = 1 - specificity, y = sensitivity, color = model)) + geom_path(lwd = 1, alpha = 0.5) + geom_abline(lty = 3) + scale_color_manual(values = c("#374785", "#E98074")) + theme(legend.position = "top") full_plot ``` ] ] .pull-right[  ] --- ### Thank you * `nflscrapR` & `nflfastR` teams 🏈 💻 * `#HANIC hosts`: Meghan and Alison 🏒 * Michael Lopez 🏈 * All y'all for listening in 🤠 ### Learn more * [`tidymodels`.org](https://www.tidymodels.org/learn/) has step by step guides of various complexities * I'll be adding additional NFL-focused examples at: [TheMockup.blog](https://themockup.blog/posts/2020-05-01-tidy-long-models/) * Julia Silge's (a `tidymodels` maintainer) [blog](https://juliasilge.com/) or [video series](https://www.youtube.com/channel/UCTTBgWyJl2HrrhQOOc710kA) * Most recent: [predicting Beach Volleyball winners](https://juliasilge.com/blog/xgboost-tune-volleyball/) w/ a tuned XGBoost model * Alison Hill's [Workshop from rstudio::conf2020](https://conf20-intro-ml.netlify.app/) * Gentle Intro to `tidymodels` on [RStudio RViews blog](https://rviews.rstudio.com/2019/06/19/a-gentle-intro-to-tidymodels/) * Julia Silge's online [free interactive course](https://supervised-ml-course.netlify.app/)
